Plano BF

PlanoBF

Design Skirting Seamless Effect
The PlanoBF Design range has been developed to be installed as part of the wall, giving a fully coordinated finish to both the wall and floor and becoming an integral element of the design. The BASE of the system is built into the wall structure, being fitted with the plaster and plasterboard (drywall). The decorative finishing profile then fixes to the BASE, creating a seamless effect.  The interlocking finishing profile can be adjusted up to 5mm in height to allow for slight undulation in the floor:

BASE Finish:  Silver Anodised Aluminium
TOP Finishes:  Silver Anodised Aluminium :  Aluminium Powder Coated - Matt White :  Wooden Oak gloss painted or natural, can be treated with a suitable coated or protective oil to achieve the required colour.









Plano Base BF 600 ANS Silver Anodised Aluminium

H=cm	Finish	Product Code
6cm	Silver Anodised Aluminium	BF 600 ASN

Material:  Extruded anodised aluminium
Colour:  Silver
Length:  2.7 metres
BASE Height:  6cm

Plano TOP BF 550 ASN Silver Anodised Aluminium

H=cm	Finish	Product Code
5.5cm	Silver Anodised Aluminium	BF 550 ASN

Material:  Extruded anodised aluminium
Colour:  Silver
Length:  2.7 metres
TOP Height:  5.5cm

Plano TOP BF 550 AM 11 Aluminium Powder Coated Matt White

H=cm	Finish	Product Code
5.5cm	Powder Coated Matt White	BF 550 ASN

Material:  Extruded anodised aluminium
Colour:  Powder Coated Matt White
Length:  2.7 metres
TOP Height:  5.5cm

Plano TOP BF 550 RO* Wooden Oak

H=cm	Finish	Product Code
5.5cm	Solid Wood - RON Natural Oak	BF 550 RON
5.5CM	Solid Wood - RO Gloss Painted Oak	BF 550 RO

Material: Solid Wood
Colour:  RON Natural Oak
Colour:  RO Gloss painted Oak
Length:  2.7 metres
TOP Height:  5.5cm


The finishing profile is available in three finishes to coordinate with any interior design, a powder coated finish to harmonize with the wall colour, anodised aluminium for a modern look or in an oak finish to complement floors and furniture.

The silver anodised aluminium BASE is installed at the same time as the wall finish to sit flush with the wall acting as the wall base and allowing the plasterworks to be neatly finished.

The TOP finishing profile is fixed once the floor and wall coverings have been fitted and allows for minor differences in floor height +/-2.5mm.

Ideal to finish spaces with a modern minimalist design.








Dimension: BASE 270 xcm L x 6cm H TOP 200cm x 5.5cm H
Dimension: 2.7 metres Base 6cm H & Top 5.5cm

Click to view product

Quantity

BI700 & BI1000

Skirting BI 700 & BI1000

Skirting BI700 Silver Anodised Interlocking Aluminium H 7cm (also available in H 10cm)

This skirting anodised aluminium profile is easy to install and allows one to cover and protect low running cables over the perimeter providing an elegant finish to low wall corners.  The internal interlocking support piece is fixed to the wall with screws or glued.
This profile is ideal for office environment or home for both aesthetic requirements and for telephone and computer wire passage.





Skirting BI 700 &1000 ASN Silver Anodised Aluminium-interlocking H 7cm & 10cm

H=cm	Finish	Product Code
7cm	Silver Anodised Aluminium	BI 700 ASN
10cm	Silver Anodised Aluminium	bi 1000 ASN
Supports		BIS 20 ANF

Skirting BI 700 ASN Silver Anodised Aluminium Interlocking H=7cm
This anodised aluminium profiles has a silver coating.  Good tolerance to oxidation and to mechanical impacts.  Relevant pre-drilled interlock-pieces (2 pcs per meter) to be purchased separately, code BIS 20 ANF.  Available junctions and end-plugs in synthetic resin Silver colour.  This skirting board is also available powder coated with RAL colour reference.


Skirting BI 700 ASN Silver Anodised Aluminium Interlocking H=10cm
This anodised aluminium profile has a silver coating.  Good tolerance to oxidation and to mechanical impacts.  Relevant pre-drilled interlock-pieces (2 pcs per meter) to be purchased separately, code BIS 20 ANF.  Available junctions and end-plugs in synthetic resin Silver colour.  This skirting board is also available powder coated with RAL colour reference.



Material: Extruded Anodised Aluminium
Colour:  Silver
Length: 2.00 metres

End-caps and Junctions for aluminium skirting BI 700 & BI 1000

Description	Product Code
Internal Corner	BII *PS
External Corner	BIE * PS
End Cap	BIT * PS

End-caps, internal and external junctions in synthetic resin with the same Silver colour, to make proper and neat junctions.  Available in 7cm height.

Material:  Polypropylene
Colour:  Silver
Height:  7cm

Dimension: 2.00 metres L x (7cm H) & (10cm H)
Dimension: 2.7 metre lengths - 7cm & 10cm H

Click to view product

Quantity

BA AS

BA-Range

Skirting BA-AS
Metal or PVC wall skirting boards to fix either with glue, screw or nails.  It is easy to install for an elegant and lasting finish.  The profile contoured ends give a snug fit on the wall covering over the bottom perimeter along the dilation gap joint, thus ensuring the necessary expansion movement to the floor.



Skirting BA-AS Silver Anodised Aluminium
Available in three heights, 4.5cm , 6cm , 8cm , 10cm
This anodised aluminium profile has a silver coating.  Good tolerance to oxidation and to mechanical impacts.  This skirting is also available in self-adhesive option of a quicker installation.



Skirting BA-AS * Silver Anodised Aluminium

H=cm	Finish	Profile Code
4.5cm	Silver Anodised Aluminium	BA 450 ASN
4.5cm	Silver Anodised Aluminium	BA 450 ASA
6cm	Silver Anodised Aluminium	BA 600 ASN
6cm	Silver Anodised Aluminium	BA 600 ASA
8cm	Silver Anodised Aluminium	BA 800 ASN
8cm	Silver Anodised Aluminium	BA 800 ASA
10cm	Silver Anodised Aluminium	BA 1000 ASN
10cm	Silver Anodised Aluminium	BA 1000 ASA



Material:  Extruded Anodised Aluminium
Colour:  Silver
Length 2.70 metres
Height:  4.5cm , 6cm , 8cm , 10cm

Available junction and end-caps in synthetic resin Silver colour for BA 6cm / 8cm H skirtings.

BA 450 / BA 600 / BA 800 / BA 1000 End-caps

Joint	Finish	Profile Code
External Corner	Anodised Silver	BAE AS
Internal Corner	Anodised Silver	BAI AS

Material:  Polypropylene
Colour:  Silver
Height:   4.5cm , 6cm , 8cm , 10cm

Skirting BA 600 A* Powder Coated Aluminium Corten / Micaceous

H=cm	Finish	Profile Code
6cm	Corten	BA 600 A60
6cm	Micaceous Grey	BA 600A50

Material:  Extruded Powder Coated Aluminium
Length: 2.00 metres
Colour:  , Micaceous Grey , Corten
Height:   6cm

Dimension: 200cm L x (4.5cm H) : (6cm H) : (8cm( H) : (10cm H)
Dimension: 2.7 metre lengths - Various Heights 450 / 600 / 800 /1000mm

Click to view product

Quantity

Skirting BAR - Multiline Ribbed Decorative Skirting

BAR

Skirting BAR - Multiline Ribbed Decorative Skirting
Decorative skirting with beautiful multiline ribbed effect in the visible part which matches the decorative standard of kitchen furniture lower plinths.  Available either pre-glued or not.  Long lasting and elegant finish.  The profile contoured ends give a snug fit on the wall covering over the bottom perimeter along the dilation gap joint, thus ensuring the necessary expansion movement to the floor.

Skirting BAR - AS* Silver Anodised Aluminium

Height= cm	Profile Code
6cm	BAR 600 ASN
6cm	BAR 600 ASA

This anodised aluminium profile has a silver coating.  Good tolerance to oxidation and to mechanical impacts.  This skirting board is also available in the self-adhesive option for a quicker installation.





Material:  Extruded Anodised Aluminium
Colour:  Silver
Length: 2 metres
Height: 6cm

END CAPS JUNCTIONS for aluminium skirting

Description	Profile Code
Internal Corner	BAI*PS
External Corner	BAE*PS

End caps, internal and external junctions in synthetic resin with the same silver colour to make proper and neat junctions.  Available in 6cm height.
Material: Polypropylene
Colour: Silver
Height: 6cm



Dimension: Length 200cm Height 6cm
Dimension: 2.7m lengths - 6cm H

Click to view product

Quantity

Skirting BA-IL Polished Stainless Steel

Skirting BA-IL * Polished Stainless Steel AISI 304 - DIN 1.4301
The stainless steel version, while meeting the last minimalist design and furnishing trends, grants an excellent resistance to most diluted chemical products.

Ideal then for applications in hospitals and food processing plants, available in brushed finish code IS.

Skirting BA IL * Polished Stainless Steel

H=cm	Finish	Product Code
6cm	Polished Stainless Steel not self-adhesive	BA 600 ILN
6cm	Polished Stainless Steel self-adhesive	BA 600 ILA
8cm	Polished Stainless Steel not self-adhesive	BA 800 ILN
8cm	Polished Stainless Steel self-adhesive	BA 800 ILA

Material:
Polished Stainless Steel:  AISI 304
Length:  2.7 metres
Height:  6cm: 8cm



Available PVC junctions and end-caps in stainless steel colour.

Joints & End-caps

Internal Corner	BAI-PA
External Corner	BAE-PI
End-cap	BAT-PI

Dimension: 2.7 metres L x 6cm or 8cm H Depth 1cm



Click to view product
Dimension: 2.7 metre lengths - 6cm & 8cm H

Click to view product

Quantity

Skirting BA 400a

BA 400

Skirting BA 400A*
Innovative skirting in metal designed to satisfy the minimalist taste in design, where the skirting performs its function while integrating in the interior design discretely and effectively.- sharp angles
- squared cross section
- height reduced to 4cm

The profile is equipped with a hollow on the invisible side which serves to glue it.  The profile is equipped with joints and special pieces with the same minimalist visual effect.



H=cm	Profile Code	Finish
4cm	BA 400 ASN	Aluminium Silver
4cm	BA 400 ASS	Anodised Aluminium Brushed
4cm	BA 400 ASB	Bright Polished Aluminium Chrome
4cm	BA 400 A 60/50	Powder Coated Aluminium Colours Corten & Micaceous Grey



Skirting BA 400 ASN Silver Anodised Aluminium & End-caps

H=cm	Profile Code
4cm	BA 400 ASN
4cm	end-caps BAC 400 ASN

 This anodised aluminium profile has a silver coating.  Good tolerance to oxidation and to mechanical impacts.
Universal external corner, internal corner and end cap.

Material:  Extruded anodised aluminium
Length: 2 metres
Height: 4cm
Colours: Silver


Skirting BA 400 ASS Brushed Aluminium Silver

H=cm	Profile Code
4cm	BA 400 ASS
4cm	end-caps BAC 400 ASS

Aluminium profile with a new silver brushed finishing according to the modern design. Universal external corner, internal corner and end-cap.

Material:  Extruded anodised aluminium
Length: 2 metres
Height: 4cm
Colours:  Brushed Silver
.
Skirting BA 400 ASB Bright Polished Aluminium Chrome

H=cm	Profile Code
4cm	BA 400 ASB
4cm	end-caps BAC 400 ASB

The surface of this anodised aluminium profile has been chrome effect treated in order  to give that sparkling effect. It holds the same properties as the other aluminium models.  Universal external corner, internal corner and end cap.

Material:  Extruded powder coated aluminium
Length: 2 metres
Height: 4cm
Colours:  Chrome

Skirting BA 400 * Powder Coated Aluminium Finishes Corten & Micaceous Grey

H=cm	Profile Code
4cm	BA 400 A 60/50
4cm	end-caps BA60/50C 400 A 60/50

Powder coated aluminium lacquered with a 60 microns polyester powder base varnish paint.  Universal external corner, internal corner and end-cap.

Material:  Extruded powder coated aluminium
Length: 2 metres
Height: 4cm
Colours:  Corten & Micaceous Grey







Skirting BA 400 ASN Silver Anodised Aluminium
This anodised aluminium profile has a silver coating.  Good tolerance to oxidation and to mechanical impacts.  Universal external corner, internal corner and end cap.



Dimension: 2.7 metre lengths - 4cm H

Click to view product

Quantity

Skirting BI - double interlocking aluminium skirting

Skirting BIB/BI 800

Skirting BI - double interlocking aluminium skirting "Bicolour Design"

Aluminium or PVC wall skirting boards fixed with glue, screws or invisible nails.  It is easy to install for an elegant and lasting finish.  The profile contoured ends give a snug fit on the wall covering over the bottom perimeter along the dilation gap joint ensuring necessary expansion movement to the floor.
A two-part skirting consisting of a silver anodised aluminium base with decorative top section.  The base section fixes directly to the wall (with mechanical or adhesive fixing) and allows the concealment of low voltage cables, in addition to offering durability and resistance from damp.  The top section is  available in a range of wood and metal effect decorative finishes and clips in to the base, covering the fixing.

Interlocking in Aluminium / Aluminium and Aluminium / Wood Bicolour effect.

RAL Powder Coating available on request minimum order 200 metres.























The base, available only in silver finish is conceived to match both the aluminium and the solid wood TOPS.  Available junctions and end plugs in synthetic resin Silver colour.

BASE BIB 800 ASN Anodised Aluminium

H=cm	Finish	Product Code
5cm	Aluminium Silver	BIB 800 ASN

Material:  extruded anodised aluminium
Length: 2 metres
Base Height: 5cm
Complete skirting Height 8cm



Skirting TOP BI 800* Top Section in various colours

H=cm	Finish	Product Code
3cm	TOP Silver Aluminium	BI 800 ANS
3cm	TOP Aluminium Anthracite	BI 800 A  50
3cm	TOP Solid Oak Gloss Painted	BI  800 RO
3cm	TOP Solid Oak - natural finish	BI 800 RON

The top section interlocks with the fixing base in silver anodised aluminium.  This skirting board composed of two separate elements allows creation of a totally innovative dual coloured effect.


Installation Guidelines:
-  screw of glue the base to the wall
-  place the provided seal into the semicircular gap every 40cm
-  insert the finishing top

Length: 2 metres
TOP Height: 3cm
Complete Skirting Height: 8cm

BI Joints & end-caps

Profile	Product Code
Internal Corner	BII800PS
External Corner	BIE800PS
End-cap	BIT800PS (Packed in a set 1R + 1L)

Dimension: 200cm L x 8cm H (BASE 5cm & TOP 3cm) Depth 1.8cm
Dimension: 2.7 metre lengths Base 5cm H & Top 3cm H

Click to view product

Quantity

BIM 800 Base & Top

Waterproofing Skirting For Outside Installation BIM 800 ASN - BASE & TOP

BIM Skirting is a technical profile for outside floors able to cover and join the waterproofing overlap.  It is a two-part skirting consisting of a silver anodised aluminium base with a decorative top section.

The base section fixes directly to the wall (with mechanical or adhesive fixing) offering durability and resistance to damp.  The top section clips into the base, covering the base.  Nice decorative effect created with two colours silver and micaceous grey.

The base, available only in silver finish is conceived to match both the aluminium and micaceous TOPS.  Available junctions and end plugs in synthetic resin Silver colour.

Skirting BIM 800 ASN - BASE

H = cm	Finish	Profile Code
5cm	Aluminium Silver	BIM 800 ASN

Skirting BI 800* TOP in different finishes

H= cm	Finish	Profile Code
3cm	Aluminium Silver	BI 800 ASN
3cm	Aluminium Micaceous Grey	BI 800 A 50

Material:  Extruded anodise aluminium
Colour: Silver
Length: 2m
Base Height: 5cm
Top Height:  3cm
Complete skirting height:  8cm

Dimension: Base 200cm L x 5cm H Top 200cm L x 3cm H
Dimension: 2.7 metre lengths - Top 4cm H & Base 5cm H

Click to view product

Quantity

Synthetic Resin Skirting

Wallprotection





Dimension: 2.7 metre Lengths 100mm H

Dimension: 2.7 metre Lenghts 100mm H

Click to view product

Quantity

Dimension: 4.5mm

Click to view product

Quantity
